Products Description
The Outdoor Ring Main Unit (RMU) is compact prefabricated medium-voltage switchgear built for ring network nodes in distribution power systems. It integrates load break switch, earthing switch, protection and metering modules within one enclosure. Fully assembled, wired and tested before factory delivery, the unit only needs positioning and fixing on site for commissioning. Manufactured to comply with IEC and GB standards for distribution equipment, it performs circuit sectionalizing, isolation and fault protection. It supports loop switching to limit outage area and improve power supply reliability of distribution networks. Thanks to its modular design, functions can be customized with protection, metering or communication modules for connection to distribution automation systems, forming a stable medium-voltage ring power supply solution.
2006
Established
20+
Years Experiences
200+
Employees
500+
Partners
our Advantages
01
All-weather sealed cabinet technology
Adopts fully sealed, all-weather protection structure
Cabinet material: aluminum alloy / stainless steel, multi-layer anti-corrosion treatment.
It has the ability to resist salt spray, ultraviolet rays, rust and corrosion.
The protection level is as high as IP67, dustproof and can be immersed in water for a short time.
Working temperature range: -30℃～+55℃
Stable operation in harsh environments such as heavy rain, heavy snow, and sand.
02
SF-free environmental protection gas insulation system
Adopts SFP-free environmental protection insulation technology, which is green and environmentally friendly.
The use of environmentally friendly dry gas, excellent insulation and arc extinguishing performance.
No risk of SFP leakage, meet modern environmental protection requirements.
The internal structure is more compact and saves installation space.
Suitable for outdoor scenes such as road green belts, narrow spaces in residential areas, etc.
03
Outdoor-level wireless monitoring module
Configure outdoor dedicated wireless monitoring module
Support 4G/5G, LoRa wireless communication
Real-time upload: switch status, insulation level, cabinet temperature and other data
Support remote monitoring, remote operation, and fault alarm
Reduce on-site inspections and improve operation and maintenance efficiency
Anti-electromagnetic interference, stable communication in outdoor electrical environment
04
Modular and quick connection structure
Modular and quick connection design
Pre-installed and debugged before leaving the factory, simple on-site installation
Functional units can be flexibly combined: load switch, circuit breaker, metering module, etc.
The later expansion and upgrade will not interrupt the operation of the power grid
Suitable for the phased construction and gradual expansion of outdoor distribution networks
Application Environment
Designed for outdoor exposed installation, the outdoor RMU can operate continuously under open-air conditions. Its operating temperature ranges from -30℃ to +55℃, adapting to large temperature swings, dust and humid climate. Anti-corrosion coating options are available for coastal salt-prone areas. The enclosure provides good dust and water ingress protection against rain, condensation and UV aging. Widely deployed in urban green belts, residential power supply points, industrial park outdoor sites, and power distribution nodes for solar and wind farms.
why choose us
Core advantages of Kechang Electric
why choose our products
State Grid bidder
Schneider Electric Partners
Equipped with five anti-interlocking safety locking devices
The average trouble-free working time of the product ＞100,000 hours
| Project | Unit | Circuit Breaker | Load Switch | Load Switch - Fuse Combinations | |
| Rated Voltage | kV | 12 | 12 | 12 | |
| Rated Frequency | A | 630/1250 | 630 | 125 | |
| Rated Current | Hz | 50 | 50 | 50 | |
| Rated Insulation Level | 1 min Power Frequency Withstand Voltage (Interphase and Phase to Ground) | kV | 12 | 42 | 42 |
| 1 min Power Frequency Withstand Voltage (Isolating Distance) | 48 | 48 | 48 | ||
| Rated Power-frequency Withstand Voltage (Control and Auxiliary Circuit) | 2 | 2 | 2 | ||
| Rated Lightning Impulse (between Phases, to Earth) | 75 | 75 | 75 | ||
| Rated Lightning Impulse (Across the Isolating Diatance) | 85 | 85 | 85 | ||
| Rated Filling Pressure (Gauge Pressure When Temperature is 20℃) | Mpa | 0.02 | |||
| Minimum Functional Pressure (Gauge Pressure When Temperature is 20℃) | Mpa | 0 | |||
| Pressure Relief Device Release Pressure (Gauge Pressure When Temperature is 20℃) | Mpa | 0.16 | |||
| Yearly Gas Leakage Rate | - | ≤0.01% | |||
| Mechanical Life | Times | 10000 | |||
| Main Loop Resistance | μΩ | ≤150 | |||
